Fixed Appliances, Palatal Expansion

Fan RPE (Rapid Palatal Expander)

The fan expander (fan RPE) allows for rapid expansion of the palate widening the arch of the anterior section while still maintaining the expansion at the molar level. This appliance self-deactivates when maximum expansion has been achieved preventing over-treatment. The Fan RPE is commonly used for patients with cleft palates and comes in 7 and 11 mm. With each expansion appliance, we provide a custom swivel key that has an integrated activation recording tool directly on the handle.
Order Now

Additional Options, Materials & Treatment Information

Treatment & Care

The Fan Expander is ideal for patients with cleft palates. Treat this appliance like a fixed expander, but consideration must be given to the activation rate predicated on the hinge location. Patients need to activate 3x per week. Four turns will produce 1mm of expander. Be aware that this appliance will have a significantly greater anterior expansion compared to mid to posterior expansion.

Clean appliance every day with toothpaste and a soft toothbrush, morning and night. Encourage the patient to give sufficient time to clean thoroughly around the appliance, gums, teeth, and bands to maintain proper hygiene and prevent inflammation. We recommend 3 minutes.

Materials

  • Wire: American Orthodontics Chromium Cobalt
  • Screw: Leone Exspider Screw 7mm or 10mm

Additional Options

  • AO Maximum Retention Bands
  • Leone Web Bands
  • .022 Slot w/ Hook
  • Headgear and .022 Slot with Hook
  • MBT w/hook
  • Double Slot w/ Hook
ODL retainer PATTERN

More About Fan RPE (Rapid Palatal Expander)

Also Known As:
Fan-type rapid palatal expander, Fan expander
Who Made Me:

Dr. Eleonora Schellino and Prof. Remo Modica designed the fan-type rapid expander in 1996. The fan-type expander is a type of rapid expansion appliance that widens the anterior region of the upper arch, while maintaining expansion at the molar level.It has become a preferred choice for patients needing anterior expansion but already possessing a well-developed posterior arch. It continues to evolve with more precise screws and mechanisms, improving patient comfort and expansion control. Especially helpful to patients with craniofacial or cleft palate diagnosis.

Contact For More Options
ODL retainer PATTERN

Customized Uniquely for You

We offer a plethora of customization options to ensure your appliance is expertly tailored to your preferences. With our array of automated machinery and highly skilled craftsmen, you can expect a consistent, high-quality product, every time.

Contact For More Options

The Dental is in the Details

We’re driven by hard-work and a relentless passion for dental excellence. It’s simple. ODL’s highly skilled lab technicians utilize the finest materials available to achieve ideal results for you and your patients. We stand by our craftsmanship and strive to exceed your expectations with every appliance.

Our Promise
ODL-dental-in-the-details-process

Revolutionize the way you serve your patients with the Fan RPE (Rapid Palatal Expander)

  • Widens the anterior palate while maintaining molar expansion
  • Stops expanding once the desired width is achieved
  • Comes with a swivel key and activation tool for precise adjustments

Let's Chat
