Fixed Appliances, Fixed Lingual Retainers

Lingual Bonded Retainer

The lingual bonded retainer is a simple yet effective appliance to prevent anterior relapse. The appliance can be bent contoured to the top 1/3 of the tooth and can be delivered by hand or within a custom template tray. Metal pads can rest on the canines or cover the entire 3-3 (6 Pads) otherwise known as the Krause appliance.
Order Now

Additional Options, Materials & Treatment Information

Treatment & Care

In office bonding procedures for Indirect Bonded Lingual Retainers.

Light Cure Adhesive

Step 1 – Optional
Insert the tray on the dental arch to familiarize yourself with the function and fit of the indirect tray.  Remove from mouth and clean with acetone. If you opted for a trial fit the pads must be cleaned with acetone to ensure a proper bond.

Step 2
To ensure a good bond between the custom pad and each tooth you will need to etch the lingual of each tooth that will be bonded according to the manufacturers guidelines of the etchant.

Step 3
Rinse each tooth to be bonded thoroughly until each tooth has a chalky appearance.

Step 4
Dry each tooth to be bonded thoroughly. Having a dry field is the most important step in achieving a good bond.

Step 5
Apply a small amount of light cure adhesive to each custom pad and to the lingual surface of each tooth to be bonded. Applying this small amount of adhesive to both surfaces is done to cover any areas of discrepancy from the impression, model pour-up and/or laboratory fabrication.

Step 6
Seat the indirect trays on the arch to be bonded and apply firm pressure into place.

Step 7
Cure the adhesive of each pad according to the manufacturers guidelines.

Step 8
After curing you may remove trays from mouth. Remove any excess flash with a small burr or scaler. Flowable composite may be used and cured around the edges of the pads to give a smooth and rounded finish.

Materials

  • Wire: American Orthodontics Lingual Retainer
ODL retainer PATTERN

More About Lingual Bonded Retainer

Also Known As:
Fixed retainer, Permanent retainer
Who Made Me:

Rupert Kneirim is credited with inventing the fixed bonded retainer in 1973. Kneirim’s retainer was made of a 0.028 inch stainless steel wire that was bonded to the lingual surfaces of the lower anterior teeth and canines.The Lingual Bonded Retainer has been in use since the 1970s as a solution for long-term retention post-orthodontic treatment. It involves bonding a wire to the back of the anterior teeth to prevent them from shifting. This retainer has been refined over time with better bonding techniques and more durable wires, making it a go-to choice for permanent retention.

Contact For More Options
ODL retainer PATTERN

Customized Uniquely for You

We offer a plethora of customization options to ensure your appliance is expertly tailored to your preferences. With our array of automated machinery and highly skilled craftsmen, you can expect a consistent, high-quality product, every time.

Contact For More Options

The Dental is in the Details

We’re driven by hard-work and a relentless passion for dental excellence. It’s simple. ODL’s highly skilled lab technicians utilize the finest materials available to achieve ideal results for you and your patients. We stand by our craftsmanship and strive to exceed your expectations with every appliance.

Our Promise
ODL-dental-in-the-details-process

Revolutionize the way you serve your patients with the Lingual Bonded Retainer

  • Simple yet effective
  • Prevent anterior relapse
  • Delivered by hand or within a custom template tray
